Drilling Cutting Fluid
Product Features:
1.Excellent anti-corrosion properties - free of phenols and nitrites, free of diethanolamine, has excellent anti-corrosion properties, especially suitable for grinding rolling rolls, ensuring that the surface does not rust for a long time after grinding.
2. Excellent Filtering Properties – Uses the latest technology and chemical surface treatments, which gives excellent resistance to oil contamination and exceptional abrasive deposition ability. This prevents abrasive particles from flowing back through the fluid supply system to the machining area, ensuring the precision of the ground surface.
3.Durability & Stability – With excellent filtering properties and hard water resistance, the Magic Power Z-17 stays clear and clean even after prolonged use. Very long service life, in central fluid supply systems, it can be used for up to 3 years without replacement, and the volume of fluid loss is minimal, which effectively reduces the processing cost.
Production:
Magic Power Z-17 is the latest chemically synthesized liquid that integrates advanced surface treatment technology. This product has excellent iron filing deposition ability and excellent anti-corrosion properties, as well as extremely low foaming rates. Special additives significantly increase the machining accuracy and service life of the abrasive wheels.
Product Features:
Excellent anti-corrosion ability – contains effective anti-corrosion and metal-saving additives that provide excellent rust protection for ferrous metals.
Excellent anti-foam properties – Due to its strong foam suppression ability, the product can operate in high-pressure systems without requiring the addition of anti-foam for a long time.
Environmental friendliness – reducing costs by reducing the dose of adding concentrate. Waste fluids do not contain substances harmful to the environment and can be discharged after treatment without harming the environment.
Test Subjects |
Control Parameter |
Test Subjects |
Control Parameter |
External condition |
Clear yellow liquid |
Flash Point (COC) |
N.a. |
Smells |
faint odor |
Conductivity/ms |
<3 |
Density (H2O=1) Refractive index |
0.98～1.11 3.0±0.2 |
pH (undiluted stock solution) pH (5% dilution 25°C) |
Not applicable 9.7±0.3 |
Cooking recommendations:
1. Recommended amount for use: for grinding with low surface and roughness requirements – 5-10%; for grinding with high surface and roughness requirements – 10–15%.
2.Typical amount to use: 5% (1:19) to 15% (1:6).
3.If the use of the product is outside the typical range, please contact us for technical support.
4.Used after mixing with water (add concentrate to water for dilution).
5. Demineralized water is recommended for dilution, which helps to extend the life of the working fluid, reduce concentrate consumption, and maximize the properties of the treatment fluid.
6. Do not add other substances to the concentrate or diluted liquid without the permission of the Magic Power technical service.
7. Concentration control can be carried out with a refractometer and refractive index to obtain the percentage of concentration of the diluted liquid: refractometer reading × refractive index = percentage concentration. (1) Before testing the sample, calibrate the refractometer with demineralized water to 0.0. (2) When taking a sample of the working fluid, choose the cleanest (no contaminants) possible.
Usage Guide:
1.Most suitable for environments with low standards or for industries where high purity is required.
2. At the initial stage of use, the product may have a faint smell, which disappears after one to two days.
3.Before using the product, clean the equipment and fluid tanks/tanks, and then add the prepared Magic Power working fluid.
4. Strictly control the concentration (add fresh liquid regularly); Usually, the addition is about 5%, and the addition of 7% contributes to a longer life of the working fluid in the tank.
5. If a floating film of oil appears in the fluid tank, it should be removed regularly to inhibit bacterial growth.
6. Do not add/mix other products without permission. If necessary, contact Magic Power for technical support.
Storage conditions:
1. Avoid direct exposure to sunlight.
2. Avoid contact with sources of fire and heat; avoid moisture.
3. Avoid contact with strong oxidizing agents, alkalis and acids.
4. After opening the package and removing part of the concentrate, close the package immediately to prevent contamination of the product.
5. Store in a well-ventilated, cool place indoors.
6. Over time, some products may darken, but this does not affect their effectiveness.
7. When freezing at low temperatures, place the product in a room with a temperature of 20°C to defrost completely, after which it can be used without loss of efficiency.
Attention:
Avoid contact with eyes and ingestion of Magic Power Z-17 Concentrate. In case of contact, rinse eyes immediately with clean, cold water or seek medical attention.
Other aspects:
Due to minor adjustments to the formula or normal changes in production, there may be slight deviations in the final product data from those shown in the table. This is normal and will not be communicated without notice!
